EuroPowerHeat is designed for commercial projects, including hotels, office buildings, factories and industrial facilities. The adaptable design of the system allows for flexible expansion to meet the energy needs of various building types and sizes.
The system integrates advanced smart safety monitoring technology to ensure safe operation while reducing energy consumption and promoting environmental protection.
Contact Us| EuroPowerHeat | ||||||
| Model | EuroPowerHeat30M | EuroPowerHeat 40M | EuroPowerHeat 80M | |||
| Seasonal Energy-(According to EN14825) | ||||||
| ErP | Energy class - Heating (35°C/55°C) | - | A+++/A+++ | A+++/A++ | A+++/A++ | |
| SCOP(35°C/55°C) | W/W | 5.00/3.83 | 4.86/3.71 | 4.8/3.6 | ||
| Rated Heat Output(Prated) (35°C/55°C) | kW | 25/24 | 28.6/28.1 | 56/54 | ||
| Seasonal Space Heating Efficiency (ηs) (35°C/55°C) | % | 197/150 | 191.5/145.7 | 190/145 | ||
| Annual Energy Consumption(35°C/55°C) | kWh | 10743/13198 | 12166/15641 | 24332/31282 | ||
| Sound power level (indoor/outdoor) | dB(A) | / | / | / | ||
| Nominal Capacity and Nominal Input | ||||||
| Nominal heating | Heating Capacity Min./Max | A7/W35 | kW | 9.52/28.95 | 12.7/38.6 | 25.5/77.2 |
| Heating Power Input Min./Max. | kW | 2.1/9.22 | 2.8/12.3 | 5.6/24.6 | ||
| C.O.P | W/W | 4.50/3.10 | 4.58/3.15 | 4.58/3.15 | ||
| Heating Capacity Min./Max | A7/W45 | kW | 8.9/28.6 | 11.9/38.2 | 23.8/76.4 | |
| Heating Power Input Min./Max. | kW | 2.4/9.6 | 3.3/12.8 | 6.6/25.6 | ||
| C.O.P | W/W | 3.60/2.80 | 3.61/2.9 | 3.61/2.9 | ||
| Nominal cooling | Cooling Capacity Min./Max | A35/W18 | kW | 9.0/25.6 | 12.1/34.2 | 24.2/68.4 |
| Cooling Power Input Min./Max. | kW | 2.1/6.8 | 2.8/9.1 | 5.6/18.2 | ||
| E.E.R | W/W | 4.20/3.70 | 4.33/3.75 | 4.33/3.75 | ||
| Cooling Capacity Min./Max | A35/W7 | kW | 3.3/18.8 | 4.5/25.1 | 9/50.2 | |
| Cooling Power Input Min./Max. | kW | 2.1/7.0 | 2.9/9.4 | 5.8/18.8 | ||
| E.E.R | W/W | 1.50/2.60 | 1.56/2.67 | 1.56/2.67 | ||
| General Info | ||||||
| Electrical data | Power supply | V/Hz/Ph | 380-420/50/3 | 380-420/50/3 | 380-420/50/3 | |
| Operation limits | Ambient Temperature Range | ℃ | -25~43 | -25~43 | -25~43 | |
| Water temperature range(heating) | ℃ | 75/20 | 75/20 | 75/20 | ||
| Water temperature range(cooling) | ℃ | 25/7 | 25/7 | 25/7 | ||
| Refrigerant side | Refrigerant | Type / Amount | - / kg | R290 / 2.5kg | R290 / 4.2kg | R290 /4.2kg * 2 |
| Compressor | Type - Quantity/System | Scroll | Scroll | Scroll | ||
| Fan | Quantity | 2 | 1 | 2 | ||
| Water Side | Type | Plate Heat Exchanger | ||||
| Water Pressure Drop | kPa | / | / | / | ||
| Piping Connection | Inch | G1-1/2" | G2" | G3" | ||
| Allowable Water Flow-Min./Rated./Max. | L/S | 1/1.4/1.8 | 1.3/1.9/2.5 | 2.6/3.8/5 | ||
| Dimension | Net Dimension(L×D×H) | Indoor Unit | mm | 390x450x132 | 390x450x132 | 390x450x132 |
| Outdoor Unit | mm | 1510x620x1735 | 1170x970x1620 | 2540x970x1650 | ||
| Net Weight | Indoor Unit | kg | 11 | 11 | 11 | |
| Outdoor Unit | kg | 249 | 320 | 612 | ||
| The specifications are subject to change without prior notice. For actual specifications of unit, please refer to the stickers on the unit. | ||||||
Uses environmentally friendly R290 refrigerant for efficient operation.
Provides heating, cooling and domestic hot water.
Supports parallel connection, suitable for various installation scenarios.
Energy efficiency class A+++@35°C, A++and above@55°C, Stable operation at -25°C, Hot water temperature up to 75°C.
